Wind Power Pitch Control System‌

Pain Points in the Application Scenario

The generator-side circuit operates under complex conditions, subject to significant harmonic and impact interference. The wind turbine system operates in harsh environments such as high temperature, high humidity, high salinity, and high altitude, and is required to withstand high-intensity vibration.

Value of the Solution

When the MCCB and MCB are used together, the breaking capacity margin is substantial, ensuring continuous power supply to the pitch system’s core equipment and the downstream shaft cabinet. The combination of an AC contactor and a thermal overload relay is used to improve the control performance of the motor in the pitch system.

QuiSure Solution

NDM3-250 Series AC MCCB, Nader

NDM3-250 Series AC MCCB, Nader

AC MCCB with rated current options: 100A, 125A, 140A, 160A, 180A, 200A, 225A, 250A. Rated voltage: AC 380/400/415V, AC 500V, AC 660/690V. Available in 3P and 4P configurations. Rated ultimate short-circuit breaking capacity: 20kA, 40kA, 50kA, 70kA, 100kA. Certified by CCC, CB, CE, TUV.

NDM3-400 Series AC MCCB, Nader

NDM3-400 Series AC MCCB, Nader

AC MCCB with rated currents of 225A, 250A, 315A, 350A, 400A and rated voltages of AC 380/400/415V, AC 500V, AC 660/690V. Available in 3P and 4P configurations. Rated ultimate short-circuit breaking capacities of 20kA, 36kA, 50kA, 70kA, 100kA. Certified by CCC, CB, CE, TUV.

NDB2T-63 Series AC/DC MCB, Nader

NDB2T-63 Series AC/DC MCB, Nader

AC/DC MCBs available with rated currents from 1A to 63A. Suitable for AC230/240/277/400/415/480V, and DC60/80/125V applications. Options include 1P, 2P, 3P, and 4P poles. High breaking capacity of 10kA. Certified by CCC, CE, TUV, UL1077, and CB. Ideal for reliable circuit protection in various electrical systems.

NDG3-160 Series AC/DC Disconnectors, Nader

NDG3-160 Series AC/DC Disconnectors, Nader

AC/DC Disconnectors with rated operational current Ie: AC80~160A, DC160A. Rated operational voltage Ue: AC 380/400/415V, AC500V, AC660/690V, AC1000V, DC 500/750V. Available in 3P and 4P configurations. Certified by CCC, CB, CE, TUV.

NDC3-38 Series AC Contactor, Nader

NDC3-38 Series AC Contactor, Nader

The NDC3-38 AC contactors are suitable for AC circuits with a frequency of 50Hz or 60Hz and a rated insulation voltage of 690V. Under the AC-3 utilization category, they are designed for AC circuits with a rated operating voltage of 400V and rated currents ranging from 9A to 38A, for frequent starting and control of AC motors.

NDR3E-38 Series Electronic Overload Relay, Nader

NDR3E-38 Series Electronic Overload Relay, Nader

NDR3E-38 electronic overload relays provide the overload, phase failure and unbalance protection for three-phase AC motors in the circuit with the AC 50Hz/60Hz, the rated voltage up to 690V and the current from 0.1A to 40A, they can be used asmotor starters with the NDC3-09~38 AC contactors.

NDD1-32 Series Motor Protection Circuit Breakers, Nader

NDD1-32 Series Motor Protection Circuit Breakers, Nader

Motor Protection Circuit Breakers, Ue:380/400/415/690V, Impulse:6kV, Power loss:2.5W/pole, Trip class:10A, Icu:10~100kA (0.1~32A).

NDZ3X-20 Series DC Contactor, Nader

NDZ3X-20 Series DC Contactor, Nader

DC Contactor with 20A rated current and DC1000V rated insulation voltage. Available coil control voltages: DC12V, DC24V. Suitable for high-voltage DC applications, ensuring reliable performance and safety. Ideal for use in renewable energy systems, electric vehicles, and industrial automation. Compact design for easy integration.

VPM220-10 (T) Series Type 3 LED SPD, VOZWEI

VPM220-10 (T) Series Type 3 LED SPD, VOZWEI

VPM220-10 (T) is a robust Type 3 SPD optimized for the terminal protection of high-voltage LED systems. Supporting Uc up to 385V AC, it handles an In of 5 kA and an Imax of 10 kA (8/20 μs). Featuring a precise Up ≤ 1.5 kV, it is fully EN/IEC 61643-11 compliant. Ideal for protecting lights, and industrial LED drivers from transient surges.
