NDC3-38 Series AC Contactor, Nader

Rated operational current Ie (A): AC38A

Rated operational voltage Ue (V): AC380/415V

Poles: 3P

Certifications: CCC, CQC, CB, CE, TUV

Wind Energy

Product Description

Application

The NDC3-38 AC contactors are suitable for AC circuits with a frequency of 50Hz or 60Hz and a rated insulation voltage of 690V. Under AC-3 (Ue 380/415 V), it provides a rated operational current (Ie) of 38 A and a thermal current (Ith, AC-1, ≤60°C) of 50 A, supporting frequent motor starting and control. Its maximum controllable three-phase motor power (AC-3) reaches 9 kW at 220/240 V and 18.5 kW from 380/400 V up to 660/690 V.

Specifications

Specifications Parameters	NDC3-38
Rated operational current (Ie)	AC-3 Ue 380/415V		38A
Conventional free-air thermal current (Ith), AC-1	θ≤ 60℃		50A
Rated insulation voltage Ui (V)	690V
Number of poles	3P
Maximum controllable three-phase motor power, AC-3 (kW)	220/240V		9kW
	380/400V		18.5kW
	415V		18.5kW
	440V		18.5kW
	500V		18.5kW
	660/690V		18.5kW
AC-3 (6le, le)	Electrical life (times)		1,200,000
	Operating frequency (times/h)		600
AC-4 (6le, 6le)	Rated operational current (380/415V)		26.7A
	Controllable three-phase motor maximum power (kW) (380/415 V)		11kW
	Electrical life (times)		45,000
	Operating frequency (times/h)		300
Mechanical life	15,000,000 times
Main circuit wiring capacity, mm² (min...max)	Flexible cable without terminal	1 piece	2.5...10
		2 pieces	2.5...10
	Flexible cable with terminal	1 piece	1...10
		2 pieces	1.5...6
	Rigid cable without terminal	1 piece	1.5...10
		2 pieces	2.5...10
Operating torque (N.m)	2.5N.m
