NDB3-50 Series HMCB, Nader

Rated current In (A): 0.5A, 1A, 2A, 2.5A, 3A, 4A, 5A, 6A, 7A, 8A, 9A, 10A, 12A, 15A, 16A, 20A, 24A, 25A, 30A, 32A, 35A, 40A, 45A, 50A

Rated voltage Ue (V): DC80V, AC120/125/240/250/415V

Poles: 1P, 2P, 3P

Breaking capacity Icn: 1000A, 1500A, 2000A, 3000A, 5000A

Documents:

Nader-NDB3-50-HMCB-Products-Specification-1302.pdf

Telecom & Data Center

OEM

Product Description

Technical parameters:

Rated voltage (V)		DC80V		DC65V	DC32V	AC240V		AC415V
Rated current (A)		1≤In≤30	30<In≤50	1≤In≤50	1≤In≤50	1≤In≤30	1≤In≤30	1≤In≤30	30<In≤50
Number of Poles		1P,2P		1P,2P	1P,2P	1P		2P,3P
Breaking capacity (A)	3C (GB/T17701)	3000A	1500A	/	/	4000(L, K) 3000(R, I)	3000(L, K) 1500(R, I)	4000(L, K) 3000(R, I)	3000(L, K) 1500(R, I)
	UL1077	3000, U1a	1500, U1a	3000, U1a	5000, U3	/	/	/	/
	UL489A	3000A	/	/	/	/	/	/	/
	UL489	/	/	/	/	/	/	/	/
	TUV/CE (EN60934)	3000A	1500A	/	/	/	/	/	/
Rated voltage (V)		AC250V		AC 125/250		AC250 3φ		AC120	AC120/240
Rated current (A)		1≤In≤30	30<In≤50	1≤In≤30	30<In≤50	1≤In≤30	30<In≤50	1≤In≤30	1≤In≤30
Number of Poles		1P		2P		3P		1P	2P,3P
Breaking capacity (A)	3C (GB/T17701)	/	/	/	/	/	/	/	/
	UL1077	5000, C1a 3000, U1a	1000, U1a	3000, U1a	2000, U3	5000, U1a	1000, U3
	UL489A	/	/	/	/	/	/	/	/
	UL489	/	/	/	/	/	/	5000	/
	TUV/CE (EN60934)	/	/	/	/	/	/	5000	/
Power frequency withstand voltage (V)		3000V(Main circuit), 1000V(Auxiliary circuit)
Standards and Certificates		·CCC, TUV, CE ·GB/T 17701, IEC 60934, EN60934, UL1077, UL489A, UL489
Tripping Curve		Z2, Z4, Z6, J2, J4, J6
Diameter of screw(mm)		M3 (6-32UNC) screw (Applied torque: 0.5N.m) M4 (8-32UNC) screw (Applied torque: 1.2N.m) M5 (10-32UNF) screw (Applied torque: 2.0N.m)
Mounting method		L, Q, M
Wiring method		L: M5 screw (≤50A) H: Solder-in/Q.C. tab (normal ≤30A, UL489≤20A) C: Push-in stud (normal≤50A, UL489≤30A) F: M5 screw with upturned lugs (normal≤50A, UL489≤30A) E: 8-32UNC screw (normal≤30A, UL489≤20A) G: 10-32UNFscrew (normal≤50A, UL489≤30A) J: 8-32UNC screw with upturned lugs (normal≤30A, UL489≤20A) K: 10-32UNF screw with upturned lugs (normal≤50A, UL489≤30A) P: M4 screw (normal≤30A, UL489≤20A) R: M4 screw with upturned lugs (normal≤30A, UL489≤20A)
Mechanical endurance		10000times
Electrical Life		6000times
Working conditions		·Operation temperature: -40℃~+85℃ ·Humidity: ≤95% ·Altitude: ≤2000m ·Service place without explosive media, gas and dust which are corrosive and conductive. ·Be mounted free from rain and snow.
